HB17 LED High Bay Light Versatile and Energy-Efficient with Adjustable Power and Color Temperature

The HB17 LED High Bay Light is the ideal choice for customizable and energy-efficient lighting. With its power-adjustable range of 60 to 300W, the HB17 can be tailored to meet the specific needs of any space. Its CCT selectable feature allows you to easily adjust the color temperature to suit different environments and preferences. Designed with MOSO power technology and Lumileds 2835 LEDs, the HB17 offers outstanding energy efficiency and long-term reliability. The built-in expansion port facilitates the addition of standard or Lightcloud Blue-enabled PIR and microwave sensors for enhanced control and further energy savings. For added convenience, a remote control option is also available. Elevate your lighting with the versatile and cost-effective HB17.

  • ● Power Tunable: 100W/ 80W/ 60W, 150W/ 120W/ 100W, 200W/ 150W/ 120W, 240W/ 200W/ 150W, 300W/ 240W/ 200W.
  • ● Light efficiency up to 160Lm/W, lumen output from 16,000Lm to 48,000Lm.
  • ● High permeability lens, beam angle 60deg, 90deg and 120deg.
  • ● IP65 water-proof, suitable for wet locations.
  • ● Maximum material utilization, good heat management, the driver is longevity and reliability.
  • ● Optional built-in smart control modules such as PIR sensor, Microwave sensor, 0-10V dimming, and Remote control.
  • ● Operating Temperature: -30°C to +50°C, -22°F~+122°F.
  • ● 5 years warranty.
Contact us
HB17 High bay Light

Sensor Optional

The heat sink comprises die-casting aluminum profiles, ensuring rapid heat conduction and excellent heat dissipation. The holes around the heat sink, facilitate the efficient dispersal of heat.

SENSOR ICON

Most Cost-Effective Highbay

Using MOSO power (0-10V dimming) and Lumileds 2835 LEDs likely contributes to its energy-efficient operation and longevity, and make it a most cost-effective high bay.

Wattage & CCT Selectable

3-in-1 Wattage Selectable

  • 100W: 60W-80W-100W
  • 150W: 100W-120W-150W
  • 200W: 120W-150W-200W
  • 240W: 150W-200W-240W
  • 300W: 200W-240W-300W

3-in-1 CCT Selectable

  • 3000K-4000K-5000K
  • 4000K-5000K-5700K

Efficient Heat Dissipation

The heat sink consists of a die-cast aluminium profile that ensures fast heat conduction and excellent heat dissipation. The small holes designed around the radiator help to reduce the operating temperature of the luminaire and extend the life of the luminaire even further.

Specifications

Model

  • HD-HB17-100W
  • HD-HB17-150W
  • HD-HB17-200W
  • HD-HB17-240W
  • HD-HB17-300W

Wattage

  • 60W-80W-100W
  • 80W-100W-150W
  • 120W-150W-200W
  • 150W-200W-240W
  • 200W-240W-300W

CCT

  • 2700K/3000K/4000K
  • 5000K/5700K/6500K

Lumen Output

  • 16,000lm
  • 24,000lm
  • 32,000lm
  • 38,400lm
  • 48,000lm

Dimming

  • 0-10V Dimming,
  • PWM

CRI

  • Ra70
  • Ra80

Certifications

  • UL/DLC/CE/CB/ENEC/ ErP/RoHS

***Please confirm the information again with our sales before placing an order.
