HB19 Dial-controlled Angle Adjustment LED High Bay Light

The HB19 Angle Adjustable High Bay sets a new standard in industrial lighting by offering wattage/CCT options from 60W to 240W, combined with a fully adjustable 3-in-1 optical lens that allows precise customization of the beam angle to 60°, 90°, or 110°. This flexibility provides optimal illumination across a wide range of applications, from warehouses and industrial facilities to large retail environments, making it an adaptable solution for various lighting needs.

  • ● Power Tunable: 100W/ 80W/ 60W, 150W/ 120W/ 80W, 200W/ 150W/ 120W, 240W/ 200W/ 150W.
  • ● Easy adjustment of the beam angle between 60°, 90° and 110°.
  • ● Light efficiency up to 160Lm/W, lumen output from 16,000Lm to 38,400Lm.
  • ● IP65 water-proof, suitable for wet locations.
  • ● Maximum material utilization, good heat management, the driver is longevity and reliability.
  • ● Optional built-in smart control modules such as PIR sensor, Microwave sensor, 0-10V dimming, and Remote control.
  • ● Operating Temperature: -30°C to +50°C, -22°F~+122°F.
  • ● 5 years warranty.
Contact us
HB19-Sensor

UGR<28

The HB19 provides exceptional lighting comfort, with a UGR<28, this means it produces minimal glare, making it comfortable for workers and reducing the risk of eye strain or discomfort. Additionally, it meets the DLC Premium standards.

Most Budget-friendly Highbay

As one of the most budget-friendly solutions on the market, the HB19 is equipped with high-performance Lumileds 2835 LEDs and a reliable Moso driver, delivering superior efficiency with up to 160 lm/W.

Sensor Optional

HB19 includes a sensor base that makes it easy to install microwave sensors, which can be configured to adjust brightness and hold time, saving additional energy and costs. A remote is also available for an additional level of control.

icon

27 fixtures in 1

Three additional switches on the housing allow for easy adjustment of the beam angle between 60°, 90° and 110°, power adjustable and CCT selectable. This innovative design not only simplifies installation, but also minimizes the need for multiple high bay models, significantly reduces storage space, reduces SKUs, simplifies logistics, and ultimately provides a more efficient and cost-effective solution, resulting in a significant reduction in operating costs.

Adjustable Angle 60°,
90° and 110°

Adjustable-Angle

CCT & Wattage Selectable

Power(W)
LOW(C)
MID(B)
HIGH(A)
60W
80W
100W
80W
120W
150W
120W
150W
200W
150W
200W
240W
CCT(K)
A(CW)
A+B(NW)
B(WW)
5700K
5000K
4000K
5000K
4000K
3000K

Specifications

Model

  • HD-HB19-100W
  • HD-HB19-150W
  • HD-HB19-200W
  • HD-HB19-240W

Wattage

  • 60W-80W-100W
  • 80W-100W-150W
  • 120W-150W-200W
  • 150W-200W-240W

CCT

  • CCT Selectable:
  • 3000K-4000K-5000K,
  • 4000K-5000K-5700K

Lumen Output

  • 16,000lm
  • 24,000lm
  • 32,000lm
  • 38,400lm

Dimming

  • 0-10V

CRI

  • Ra70
  • Ra80

Certifications

  • UL/DLC/CE/CB/ErP/RoHS

***Please confirm the information again with our sales before placing an order.
