Marvel Plus Sports Lighting Solutions with 3-IN-1 Power Selectable

The T19S is a cost-effective sports lighting solution for the stadium, which can 1:1 replacement for the HID and is also friendly to the new sports fields. The engineers designed a lighter weight and two handles to simplify the installations. Opto-electrical separation solutions are advantageous to the flexible installation of the power supply, which can be installed on the lamp holder and the lamp post, and can also be installed on the distribution box, for the convenience of installation and later maintenance.

  • ● Wattage can be adjusted from 700W-800W-900W and 800W-900W-1000W.
  • ● Light efficiency has 150Lm/W and 140Lm/W optional, Lumen output from 98,000Lm to 150,000Lm.
  • ● Color temperature from 2700K to 6500K for choose.
  • ● Beam angle 10°, 15°, 20°, 40°, 60°.
  • ● IK10 explosion-proof and IP66 water proof.
  • ● Operating Temperature: -40℃ to +50℃.
  • ● Life Span L70B50 10,0000h@25℃.
  • ● Certificates UL, DLC, CE, CB, ENEC, RoHS.
  • ● 5 years, 7 years optional.
Contact us

Small Size to Reduce Costs

Small size make a small wind resistance，reduce packing size, and save transportation space and freight.

Lightweight Stadium Light

Light weight, 1000W only 20kg, kindly to simplify the installations.

Opto-electrical Separation

Opto-electrical separation solutions make the driver separate from the heat sink, extending the overall lamp life.

Excellent Heat Dissipation

The vents help the air convection to dissipate heat. A high thermal conductivity aluminum heat sink can quickly spread out the heat. So the low junction temperature during high power operation has ensured a long life and stable performance of LEDs.

Corrosion Resistant Surface Treatment

T19S adopt surface powder coated, which has strong corrosion resistance, suitable for the air environment in more harsh areas, especially in coastal cities.

Marvel Plus Sports Lighting 7
Marvel Plus Sports Lighting 8

LENS

High-temperature-rated and high transmittance lens materials for less light loss and a long span life, multiple beams spreads to meet custom project requirements, and provide maximum light control.

Specifications

Model

  • HD-FL19 Plus-900W
  • HD-FL19 Plus-1000W

Wattage

  • 3-in-1 watt selectable 700W-800W-900W
  • 3-in-1 watt selectable 800W-900W-1000W

CCT

  • 2700K/3000K/4000K/
  • 5000K/5700K/6500K

Lumen Output

  • 98,000lm-135,000lm
  • 112,000lm-150,000lm

Dimming

  • 0-10V/1-10V/DALI/ DMX512/Synapse

CRI

  • ≥70

Certifications

  • UL/DLC/CE/CB/ENEC/RoHS

***Please confirm the information again with our sales before placing an order.
